Maxim Integrated, DAC Quad 12 bit-, 24-Pin TQFN-EP
RS Stock No. 191-3980
Brand Maxim Integrated
Manufacturers Part No. MAX5135GTG+
150 in stock in the UK
150 in stock in the UK
$ 6.264
Each (In a Tube of 75)
Maxim Integrated, DAC Quad 12 bit-, 24-Pin TQFN-EP
Live stock
150 in stock in the UK
Specifications
Brand
Maxim Integrated
Architecture
Resistor String
Resolution
12 bit
Integral Nonlinearity Error
±6LSB
Number of DAC Channels
4
Mounting Type
Surface Mount
Package Type
TQFN-EP
Pin Count
24
Maximum Settling Time
5µs
Output Polarity
Bipolar, Unipolar
Voltage Reference
External, Internal
Power Supply Type
Single
Minimum Operating Temperature
-40 °C
Typical Single Supply Voltage
2.7 to 5.25 V
Dimensions
4.1 x 4.1 x 0.75mm
Maximum Operating Temperature
105 °C
