TE Connectivity, Ultra-Fast Plus .250 Red Insulated Spade Connector, 6.35 x 0.81mm Tab Size, 0.3mm² to 0.8mm²
19 in stock in the UK
$ 726.27
1 Pack of 1400
Buy in bulk
| quantity | Unit price |
|---|---|
| 1 - 1 | $ 726.27 |
| 2 - 3 | $ 689.95 |
| 4+ | $ 660.90 |
Live stock
19 in stock in the UK
Product details
TE Connectivity FASTON 250 Series Ultra-Fast Plus Tab Crimp Terminal
FASTON 250 series Ultra-Fast Plus fully insulated tab crimp terminals designed to prevent shock and electrical short circuits from exposed leads. The housings of these FASTON 250 series Ultra-Fast plus tab crimp terminals completely enclose a tin plated copper alloy FASTON tab contact which is recessed within the housing to allow its use in 600V applications. The tab and wire barrel part of the housing is made from type 6/6 nylon whilst the insulation barrel is made from premium grade nylon with minimum spring-back which retains the insulation crimp shape and provides strain relief. These FASTON 250 series Ultra-fast plus crimp terminals terminate 26-10 AWG solid, fused and stranded wire.
TE Connectivity Ultra-Fast and Ultra-Fast Plus Terminals
Specifications
Brand
TE Connectivity
Minimum Wire Size mm²
0.3mm²
Maximum Wire Size mm²
0.8mm²
Insulation
Insulated
Gender
Male
Tab Size
6.35 x 0.81mm
Colour
Red
Tab Width
6.35mm
Tab Thickness
0.81mm
Minimum Wire Size AWG
22AWG
Maximum Wire Size AWG
18AWG
Termination Method
Crimp
Contact Material
Brass
Contact Plating
Tin
Overall Length
21.71mm
Insulation Material
Nylon
Series
Ultra-Fast Plus .250
