Maxim Integrated MAX6509HAUK+T, Temperature Sensor Switch -40 to +125 °C ±0.5°C, 6-Pin SOT-23
Temporarily out of stock
$ 1.815
Each (In a Pack of 5)
Buy in bulk
| quantity | Unit price |
|---|---|
| 5 - 20 | $ 1.815 |
| 25 - 45 | $ 1.598 |
| 50 - 245 | $ 1.308 |
| 250 - 495 | $ 1.163 |
| 500+ | $ 1.090 |
Live stock
Temporarily out of stock
Product details
MAX6509/6510 Resistor Programmable Temperature Switches
The MAX6509 and 6510 series of resistor programmable temperature switches rely on an external resistor to set the required temperature threshold.
The MAX6509 switch has an open drain output whilst the MAX6510 switch has 3 output options - active low, active high and open drain with an internal pull-up resistor.
The switches are ideal for temperature/fan control and temperature monitoring applications.
Temperature & Humidity Sensors, Maxim Integrated
Specifications
Brand
Maxim Integrated
Sensor Function
Temperature Switch
Output Type
Open Drain
Accuracy
±0.5°C
Mounting Type
Surface Mount
Pin Count
6
Minimum Operating Temperature
-40 °C
Operating Temperature Range
-40 to +125 °C
Maximum Operating Temperature
+125 °C
Minimum Operating Supply Voltage
2.7 V
Maximum Operating Supply Voltage
5.5 V
Package Type
SOT-23
Length
3mm
Height
1.3mm
Width
1.75mm
Dimensions
3 x 1.75 x 1.3mm
Country of Origin
TH
Technical Document
RoHS Certificate of Compliance
Statement of Conformity
