Maxim Integrated 154ns CMOS Delay Line, 16-Pin SOIC
46 in stock in the UK
$ 11.698
Each (In a Tube of 46)
Buy in bulk
| quantity | Unit price |
|---|---|
| 46 - 92 | $ 11.698 |
| 138 - 230 | $ 11.114 |
| 276 - 966 | $ 10.088 |
| 1012+ | $ 9.835 |
Live stock
46 in stock in the UK
Product details
Delay Lines, Maxim Integrated Products
Delay Lines
Specifications
Brand
Maxim Integrated
Logic Family
74F04
Logic Function
Delay Line
Input Signal Type
CMOS
Mounting Type
Surface Mount
Package Type
SOIC
Pin Count
16
Dimensions
10.5 x 7.6 x 2.35mm
Total Number of Taps
8
Absolute Increment
63.75ns
Delay to First Tap
0.25ns
Maximum Delay Time
154ns
Maximum Operating Supply Voltage
5.25 V
Maximum Operating Temperature
+70 °C
Number of Independent Delay Inputs
1
Minimum Operating Temperature
0 °C
Minimum Operating Supply Voltage
4.75 V
Country of Origin
PH
