Renesas Electronics R5F5651EDDBP#20, 32bit RXv2 CPU Microcontroller, RX65N, 120MHz, 2 MB Flash, 64-Pin TFBGA

Brand

Renesas Electronics

Family Name

RX65N

Package Type

TFBGA

Mounting Type

Surface Mount

Pin Count

64

Device Core

RXv2 CPU

Data Bus Width

32bit

Program Memory Size

2 MB

Maximum Frequency

120MHz

RAM Size

640 kB

USB Channels

1

ADC Channels

29

Number of SPI Channels

3

Typical Operating Supply Voltage

3.6 (Maximum) V

Timer Resolution

8 bit, 16 bit, 32bit

Height

0.95mm

Width

4.58mm

ADC Resolution

12bit

Minimum Operating Temperature

-40 °C

Dimensions

4.58 x 4.58 x 0.95mm

Instruction Set Architecture

CISC

Number of CAN Channels

2

Number of ADC Units

2

Program Memory Type

Flash

Maximum Operating Temperature

+85 °C

Length

4.58mm

ADCs

2 (29 x 12 bit)

Number of Timers

3

Number of I2C Channels

3
