P-Channel MOSFET, 18 A, 100 V, 3-Pin TO-3 Magnatec IRF9140

Brand

Magnatec

Channel Type

P

Maximum Continuous Drain Current

18 A

Maximum Drain Source Voltage

100 V

Package Type

TO-3

Mounting Type

Through Hole

Pin Count

3

Maximum Drain Source Resistance

200 mΩ

Channel Mode

Enhancement

Maximum Gate Threshold Voltage

4V

Maximum Power Dissipation

125 W

Transistor Configuration

Single

Maximum Gate Source Voltage

-20 V, +20 V

Number of Elements per Chip

1

Minimum Operating Temperature

-55 °C

Typical Gate Charge @ Vgs

60 nC @ 10 V

Height

7.87mm

Maximum Operating Temperature

+150 °C

Length

39.95mm

Width

26.67mm

Transistor Material

Si

Country of Origin

GB
