P-Channel MOSFET Transistor, 21 A, 100 V, 3-Pin TO-247AC VISHAY IRFP9140
RS Stock No. 189-0949
Brand Vishay
Manufacturers Part No. IRFP9140
Permanently discontinued
Permanently discontinued
P.O.A
P-Channel MOSFET Transistor, 21 A, 100 V, 3-Pin TO-247AC VISHAY IRFP9140
Live stock
Permanently discontinued
Specifications
Brand
Vishay
Channel Type
P
Maximum Continuous Drain Current
21 A
Maximum Drain Source Voltage
100 V
Package Type
TO-247AC
Mounting Type
Through Hole
Pin Count
3
Maximum Drain Source Resistance
200 mΩ
Channel Mode
Enhancement
Maximum Power Dissipation
180 W
Maximum Gate Source Voltage
-20 V, +20 V
Number of Elements per Chip
1
Minimum Operating Temperature
-55 °C
Maximum Operating Temperature
+175 °C
Length
15.87mm
Typical Gate Charge @ Vgs
61 nC @ 10 V
Height
20.7mm
Width
5.31mm
