STMicroelectronics L6470PDTR, Stepper Motor Stepper Motor Driver 36-Pin, SOIC
RS Stock No. 188-8273
Brand STMicroelectronics
Manufacturers Part No. L6470PDTR
1800 in stock in the UK
1800 in stock in the UK
$ 4.875
Each (On a Reel of 600)
STMicroelectronics L6470PDTR, Stepper Motor Stepper Motor Driver 36-Pin, SOIC
Buy in bulk
| quantity | Unit price |
|---|---|
| 600 - 600 | $ 4.875 |
| 1200 - 1800 | $ 4.252 |
| 2400+ | $ 4.086 |
Live stock
1800 in stock in the UK
Specifications
Brand
STMicroelectronics
Motor Type
Stepper Motor
Output Configuration
Bipolar
Configuration
Full Bridge
Maximum Output Current
3 (RMS A, 7 (Pulsed) A
Maximum Supply Voltage
45 V
Mounting Type
Surface Mount
Package Type
SO
Maximum Operating Supply Voltage
45 V
Pin Count
36
Minimum Operating Supply Voltage
8 V
Typical Switching Frequency
800kHz
Product Length
9.8mm
Product Height
1.05mm
Minimum Operating Temperature
-40 °C
Dimensions
9.8 x 4.5 x 1.05mm
Product Width
4.5mm
Maximum Operating Temperature
+150 °C
Length
9.8mm
Height
1.05mm
Width
4.5mm
