Microchip PIC18F26Q10-I/SP, 8bit CPU Microcontroller, PIC18F, 64MHz, 64 kB Flash, 28-Pin PDIP

Brand

Microchip

Family Name

PIC18F

Package Type

PDIP

Mounting Type

Through Hole

Pin Count

28

Device Core

CPU

Data Bus Width

8bit

Program Memory Size

64 kB

Maximum Frequency

64MHz

RAM Size

3.615 kB

Number of PWM Units

1

ADC Channels

24

Number of SPI Channels

2

Typical Operating Supply Voltage

1.8 → 5.5 V

Timer Resolution

8 bit, 16bit

Height

3.81mm

PWM Channels

2

Width

7.37mm

ADC Resolution

10bit

Pulse Width Modulation

1 (2 x 10 bit)

Instruction Set Architecture

RISC

Number of USART Channels

2

Minimum Operating Temperature

-40 °C

Dimensions

1.4 x 0.29 x 0.15in

PWM Resolution

10bit

Number of ADC Units

1

Program Memory Type

Flash

Maximum Operating Temperature

+85 °C

Number of UART Channels

2

Length

35.56mm

ADCs

1 (24 x 10 bit)

Number of Timers

2

Number of I2C Channels

2
