Nichicon 10μF Electrolytic Capacitor 50V dc, Surface Mount - UUD1H100MCL1GS
RS Stock No. 187-2331
Brand Nichicon
Manufacturers Part No. UUD1H100MCL1GS
1100 in stock in the UK
1100 in stock in the UK
$ 0.285
Each (In a Pack of 25)
Nichicon 10μF Electrolytic Capacitor 50V dc, Surface Mount - UUD1H100MCL1GS
Buy in bulk
| quantity | Unit price |
|---|---|
| 25 - 25 | $ 0.285 |
| 50 - 75 | $ 0.242 |
| 100 - 475 | $ 0.213 |
| 500 - 1975 | $ 0.185 |
| 2000+ | $ 0.171 |
Live stock
1100 in stock in the UK
Specifications
Brand
Nichicon
Capacitance
10µF
Voltage
50V dc
Mounting Type
Surface Mount
Technology
Electrolytic
Dimensions
6.6 x 6.6 x 5.8mm
Height
5.8mm
Length
6.6mm
Depth
6.6mm
Minimum Operating Temperature
-55°C
Diameter
6.3mm
Maximum Operating Temperature
+105°C
Lead Pitch
2.2mm
Lifetime
2000h
Series
UD
Ripple Current
165mA
Dissipation Factor
0.12%
Polarised
Polar
Leakage Current
3 μA
Tolerance
±20%
Country of Origin
JP
