Nichicon 220μF Electrolytic Capacitor 16V dc, Through Hole - UPM1C221MPD
RS Stock No. 187-2230
Brand Nichicon
Manufacturers Part No. UPM1C221MPD
3400 in stock in the UK
3400 in stock in the UK
$ 0.175
Each (In a Bag of 200)
Nichicon 220μF Electrolytic Capacitor 16V dc, Through Hole - UPM1C221MPD
Live stock
3400 in stock in the UK
Specifications
Brand
Nichicon
Capacitance
220µF
Voltage
16V dc
Mounting Type
Through Hole
Technology
Electrolytic
Dimensions
8 Dia. x 11.5mm
Height
11.5mm
Minimum Operating Temperature
-55°C
Diameter
8mm
Maximum Operating Temperature
+105°C
Lead Pitch
3.5mm
Lifetime
3000h
Series
PM
Ripple Current
460mA
Dissipation Factor
0.16%
Polarised
Polar
Leakage Current
4 μA
Tolerance
±20%
