Nichicon 100μF Electrolytic Capacitor 50V dc, Through Hole - UHE1H101MPD
RS Stock No. 187-2226
Brand Nichicon
Manufacturers Part No. UHE1H101MPD
3000 in stock in the UK
3000 in stock in the UK
$ 0.208
Each (In a Bag of 200)
Nichicon 100μF Electrolytic Capacitor 50V dc, Through Hole - UHE1H101MPD
Buy in bulk
| quantity | Unit price |
|---|---|
| 200 - 400 | $ 0.208 |
| 600 - 1000 | $ 0.166 |
| 1200+ | $ 0.153 |
Live stock
3000 in stock in the UK
Specifications
Brand
Nichicon
Capacitance
100µF
Voltage
50V dc
Mounting Type
Through Hole
Technology
Electrolytic
Dimensions
8 Dia. x 11.5mm
Height
11.5mm
Minimum Operating Temperature
-40°C
Diameter
8mm
Maximum Operating Temperature
+105°C
Lead Pitch
3.5mm
Lifetime
7000h
Series
HE
Ripple Current
555mA
Dissipation Factor
0.1%
Polarised
Polar
Leakage Current
3 μA
Tolerance
±20%
