Nichicon 10μF Electrolytic Capacitor 400V dc, Through Hole - UCY2G100MPD
RS Stock No. 187-2214
Brand Nichicon
Manufacturers Part No. UCY2G100MPD
1400 in stock in the UK
1400 in stock in the UK
$ 0.473
Each (In a Bag of 200)
Nichicon 10μF Electrolytic Capacitor 400V dc, Through Hole - UCY2G100MPD
Buy in bulk
| quantity | Unit price |
|---|---|
| 200 - 200 | $ 0.473 |
| 400+ | $ 0.400 |
Live stock
1400 in stock in the UK
Specifications
Brand
Nichicon
Capacitance
10µF
Voltage
400V dc
Mounting Type
Through Hole
Technology
Electrolytic
Dimensions
10 Dia. x 16mm
Height
16mm
Minimum Operating Temperature
-40°C
Diameter
10mm
Maximum Operating Temperature
+105°C
Lead Pitch
5mm
Lifetime
10000h
Series
CY
Leakage Current
0.26 (Short Term) μA
Tolerance
±20%
Ripple Current
150mA
Dissipation Factor
0.24%
Polarised
Polar
