Nichicon 100μF Electrolytic Capacitor 25V dc, Surface Mount - UCL1E101MCL6GS
RS Stock No. 187-2213
Brand Nichicon
Manufacturers Part No. UCL1E101MCL6GS
4000 in stock in the UK
4000 in stock in the UK
$ 0.169
Each (On a Reel of 1000)
Nichicon 100μF Electrolytic Capacitor 25V dc, Surface Mount - UCL1E101MCL6GS
Buy in bulk
| quantity | Unit price |
|---|---|
| 1000 - 1000 | $ 0.169 |
| 2000+ | $ 0.162 |
Live stock
4000 in stock in the UK
Specifications
Brand
Nichicon
Capacitance
100µF
Voltage
25V dc
Mounting Type
Surface Mount
Technology
Electrolytic
Dimensions
8.3 x 8.3 x 6.2mm
Height
6.2mm
Length
8.3mm
Depth
8.3mm
Minimum Operating Temperature
-55°C
Diameter
8mm
Maximum Operating Temperature
+105°C
Lead Pitch
2.3mm
Lifetime
2000h
Series
CL
Ripple Current
500mA
Dissipation Factor
0.14%
Polarised
Polar
Leakage Current
3 μA
Tolerance
±20%
Country of Origin
JP
