Winslow 2.54mm Pitch Vertical 28 Way, Through Hole Turned Pin Open Frame IC Dip Socket, 5A
364 in stock in the UK
$ 2.174
Each (In a Tube of 14)
Buy in bulk
| quantity | Unit price |
|---|---|
| 14 - 336 | $ 2.174 |
| 350 - 1036 | $ 1.958 |
| 1050 - 2786 | $ 1.740 |
| 2800 - 5586 | $ 1.523 |
| 5600+ | $ 1.415 |
Live stock
364 in stock in the UK
Product details
Winslow Adaptics W30600 Series Wire Wrap DIL IC Sockets
W30600 Series Level 3 wire wrap DIL IC sockets with an open frame housing. These DIL IC sockets have screw machined (turned) half hard brass outer pins with a beryllium copper contact. The contact is gold plated and the outer pins have a pure bright tin plating. The pins of these wire wrap DIL IC sockets feature a straight knurled barrel which prevents the pin rotating during the wrapping process. The frame is made from PBT with a UL 94 V-0 rating.
IC Sockets-DIP Turned Pin
Specifications
Brand
Winslow
Number Of Contacts
28
Mounting Type
Through Hole
Pin Type
Turned
Pitch
2.54mm
Row Width
7.62mm
Frame Type
Open Frame
Termination Method
Wire Wrap
Contact Plating
Gold, Tin
Current Rating
5A
Orientation
Vertical
Length
35.48mm
Width
10.14mm
Depth
3mm
Dimensions
35.48 x 10.14 x 3mm
Housing Material
Glass Fibre Reinforced PBT
Contact Material
Beryllium Copper
Minimum Operating Temperature
-65°C
Maximum Operating Temperature
+150°C
Country of Origin
GB
