Bourns SM8SF24CA-Q, Dual-Element Bi-Directional TVS Diode, 7000W, 2-Pin DFN
RS Stock No. 187-1513
Brand Bourns
Manufacturers Part No. SM8SF24CA-Q
750 in stock in the UK
750 in stock in the UK
$ 1.198
Each (In a Pack of 5)
Bourns SM8SF24CA-Q, Dual-Element Bi-Directional TVS Diode, 7000W, 2-Pin DFN
Buy in bulk
| quantity | Unit price |
|---|---|
| 5 - 20 | $ 1.198 |
| 25 - 95 | $ 2.967 |
| 100 - 245 | $ 2.889 |
| 250 - 495 | $ 2.814 |
| 500+ | $ 2.747 |
Production pack (Reel)
Live stock
750 in stock in the UK
Specifications
Brand
Bourns
Direction Type
Bi-Directional
Minimum Breakdown Voltage
26.7V
Mounting Type
Surface Mount
Package Type
DFN
Maximum Reverse Stand-off Voltage
24V
Pin Count
2
Peak Pulse Power Dissipation
7000W
ESD protection
Yes
Number of Elements per Chip
2
Minimum Operating Temperature
-55 °C
Maximum Operating Temperature
+175 °C
Height
1.3mm
Width
8.1mm
Test Current
5mA
Maximum Reverse Leakage Current
10µA
Surge Current Rating
180 (Reverse)A
Dimensions
10.5 x 8.1 x 1.3mm
Working Voltage
24V
Automotive Standard
AEC-Q101
Length
10.5mm
Country of Origin
TW
