Bourns SM8S36CA-Q, Bi-Directional TVS Diode, 6600W, 2-Pin DO-218
RS Stock No. 187-1411
Brand Bourns
Manufacturers Part No. SM8S36CA-Q
Temporarily out of stock
Back order for despatch on 10/12/2021
Temporarily out of stock
$ 1.517
Each (On a Reel of 750)
Bourns SM8S36CA-Q, Bi-Directional TVS Diode, 6600W, 2-Pin DO-218
Buy in bulk
| quantity | Unit price |
|---|---|
| 750 - 750 | $ 1.517 |
| 1500 - 1500 | $ 1.458 |
| 2250+ | $ 1.422 |
Live stock
Temporarily out of stock
Back order for despatch on 10/12/2021
Specifications
Brand
Bourns
Direction Type
Bi-Directional
Minimum Breakdown Voltage
40V
Mounting Type
Surface Mount
Package Type
DO-218
Maximum Reverse Stand-off Voltage
36V
Pin Count
2
Peak Pulse Power Dissipation
6600W
ESD protection
Yes
Number of Elements per Chip
1
Minimum Operating Temperature
-55 °C
Maximum Operating Temperature
+175 °C
Width
8.5mm
Test Current
5mA
Maximum Reverse Leakage Current
10µA
Surge Current Rating
114 (Reverse)A
Dimensions
13.5 x 8.5 x 4.85mm
Working Voltage
36V
Automotive Standard
AEC-Q101
Length
13.5mm
Height
4.85mm
Country of Origin
TW
